AS a professional PCB manufacturer in China started in 2003, until now we have produced all kinds of PCBs including FR4, FR1, CEM1, FPC, Metal Core PCB and Rogers PCB, etc. With the advantage of material and component sourcing channels, we have the ability of fast PCB sample--48 hours after order confirmation.
PCB Specifications
| PCB layer | 1, 2, 4 or 6, up to 18 layers | |||||||
| Board shape | Rectangular, round, slots, cutouts, complex, irregular | |||||||
| Board type | Rigid, flexible, rigid-flexible | |||||||
| Board material | FR-4 glass epoxy, FR4 High Tg, RoHS compliant; Aluminum, Rogers, etc. | |||||||
| Board cutting | Shear, V-score, tab-routed | |||||||
| Board thickness | 0.2 ~ 4.0 mm (±10%), Flex board: 0.01 ~ 0.25″ (±10%) | |||||||
| Copper weight | 1.0, 1.5, 2.0 Oz (tolerance ±0.25 oz) | |||||||
| Solder mask | Double-sided green LPI, Also support red, white, yellow, blue, black | |||||||
| Silk screen | Double-sided or single-sided in white,yellow, black, or negative | |||||||
| Silk screen min. line width | 0.006″ or 0.15mm | |||||||
| Max board dimension | 20 inch *20 inch or 500mm*500mm | |||||||
| Min. trace/gap | 0.10mm, or 4 mils | |||||||
| Min. drill hole diameter | 0.01”, 0.25mm, or 10 mils | |||||||
| Surface finish | HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc. | |||||||
| Min.slot width | 0.12”, 3.0 mm, or 120 mils | |||||||
| V-score depth | 20-25% of board thickness | |||||||
| Plated through holes | Yes | |||||||
| Design file format | Gerber RS274X, 274D, Eagle and AutoCAD’s, DXF, DWG, Protel 99se | |||||||
Fast Delivery
| Order Types/PCB Layers | 1/2-layer | 4-layer | 6-layer | Above 8-layer | HDI | ||||||
| Normal Sample Orders | 5-6 days | 6-7 days | 7-8 days | 10-12 days | 15-20 days | ||||||
| Fast Sample Orders | 48-72 hours | 5 days | 6 days | 6-7 days | 12 days | ||||||
| First Batch Orders | 7-9 days | 10-12 days | 13-15 days | 16 days | 20 days | ||||||
-
